Product Summary

The BQ24721C is a high efficiency synchronous battery pack charger with high level of integration for portable applications. This device implements a high performance analog front-end that interfaces to the system power management micro-controller through a simplified SBS-like SMBus interface. The dynamic power management (DPM) function of BQ24721C modifies the charge current depending on system load conditions, avoiding ac adapter overload.

Parametrics

BQ24721C absolute maximum ratings: (1)Supply voltage range: -0.3 V to 30 V at ACN, ACP, PVCC, ACDRV, SYNN, SYNP, SRP, SRN, BATDRV, BAT, BYPASS, SYS, VCC, -1 V to 30 V at PH, –0.3 V to 7 V at LODRV, REGN, FBO, EAI, EAO, ISYNSET, CHGEN, TS , VREF5, ACDET, IOUT, ALARM, SCL, SDA, –1 V to 36 V at BTST, HIDRV (with respect to AGND and PGND); (2)Maximum differential voltage: -0.3 V to 0.3 V; (3)Maximum difference voltage: 0.6 V; (4)Operating ambient temperature range: –40℃ to 85℃; (5)Maximum junction temperature: 150℃; (6)Storage temperature range: -65℃ to 150℃.

Features

BQ24721C features: (1)High Efficiency NMOS-NMOS Synchronous Buck Converter With User-Selectable 300 kHz or 500 kHz frequency; (2)bq24721C Offers Softer Turn-On, Stronger Turn-Off; (3)SBS-Like SMBus Interface for Control and Status Communications With Host; (4)Programmable Battery Voltage, Charge Current, and AC Adapter Current via SBS-Like SMBus Interface; (5)0.4% Charge Voltage Regulation Accuracy; (6)3% Charge Current Regulation Accuracy; (7)3% Adapter Current Regulation Accuracy Dynamic Power Management (DPM).

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
BQ24721C
BQ24721C

Other


Data Sheet

Negotiable
BQ24721CRHBR
BQ24721CRHBR

Texas Instruments

Battery Management Smart Battery Charger

Data Sheet

0-2260: $2.30
2260-3000: $2.22
BQ24721CRHBTG4
BQ24721CRHBTG4

Texas Instruments

Battery Management Smart Battery Charger

Data Sheet

0-163: $3.07
163-250: $2.80
250-500: $2.52
500-1000: $2.48
BQ24721CRHBT
BQ24721CRHBT

Texas Instruments

Battery Management Smart Battery Charger

Data Sheet

0-163: $3.07
163-250: $2.80
250-500: $2.52
500-1000: $2.48
BQ24721CRHBRG4
BQ24721CRHBRG4

Texas Instruments

Battery Management Smart Battery Charger

Data Sheet

0-2410: $2.16
2410-3000: $2.14
