MC705C8ACPE

4MHZ, 8K, OTP, 40-DIP, 8 bit microcontroller unit, 304 x 8, 2.1MHz, 3 V ~ 5.5 V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $5.00~7.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $5.00~7.00

PartNumber:: MC705C8ACPE

Brand:: Freescale Semiconductor, Inc - Freescale | Pack: DIP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Kendy Chen's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-12-14

From Other Seller

Part Number:MC705C8ACPE
US $5.00 - 7.00
EKZE250ELL152MK25S

US $0.10 - 1.00 / Piece
(0) Remove
HEF4051BT

US $0.15 - 1.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The MC705C8ACPE is a member of the low-cost, high-performance M68HC05 Family of 8 bit microcontroller units (MCU). It is based on the customer-specified integrated circuit (CSIC) design strategy. The MC705C8ACPE uses the M68HC05 central processor unit (CPU) and is available with a variety of subsystems, memory sizes and types, and package types.

Parametrics

MC705C8ACPE absolute maxing ratings: (1)Supply voltage VDD: -0.3 to +7.0 V; (2)Input voltage VIn: VSS –0.3 to VDD +0.3 V; (3)Programming voltage VPP: VDD –0.3 to 16.0; (4)Bootstrap mode (IRQ pin only) VIn: VSS – 0.3 to 2 × VDD + 0.3 V; (5)Current drain per pin excluding VDD and VSS I: 25 mA; (6)Storage temperature range TSTG: -65 to +150 ℃.

Features

MC705C8ACPE features: (1)On-chip oscillator with crystal/ceramic resonator; (2)Memory-mapped input/output (I/O); (3)Selectable memory configurations; (4)Selectable programmable and/or non-programmable computer operating properly (COP) watchdog timers; (5)Selectable port B external interrupt capability; (6)Clock monitor; (7)High current drive on pin C7 (PC7); (8)24 bidirectional I/O lines and 7 input-only lines.
