Product Summary

The MMA7361LCT is a low power, low profile capacitive micromachined accelerometer featuring signal conditioning, a 1-pole low pass filter, temperature compensation, self test, 0g-Detect which detects linear freefall, and g-Select which allows for the selection between 2 sensitivities. Zero-g offset and sensitivity are factory set and require no external devices. The MMA7361LCT includes a Sleep Mode that makes it ideal for handheld battery powered electronics. The applications of the MMA7361LCT include 3D Gaming: Tilt and Motion Sensing, Event Recorder, HDD MP3 Player: Freefall Detection, Laptop PC: Freefall Detection, Anti-Theft, Cell Phone: Image Stability, Text Scroll, Motion Dialing, E-Compass, Pedometer: Motion Sensing, PDA: Text Scroll, Navigation and Dead Reckoning: E-Compass Tilt Compensation, Robotics: Motion Sensing.

Parametrics

MMA7361LCT absolute maximum ratings: (1)Maximum Acceleration (all axis): ±5000 g; (2)Supply Voltage: –0.3 to +3.6 V; (3)Drop Test: 1.8 m; (4)Storage Temperature Range: –40 to +125 ℃.

Features

MMA7361LCT features: (1)3mm x 5mm x 1.0mm LGA-14 Package; (2)Low Current Consumption: 400 μA; (3)Sleep Mode: 3 μA; (4)Low Voltage Operation: 2.2 V - 3.6 V; (5)High Sensitivity (800 mV/g @ 1.5g); (6)Selectable Sensitivity (±1.5g, ±6g); (7)Fast Turn On Time (0.5 ms Enable Response Time); (8)Self Test for Freefall Detect Diagnosis; (9)0g-Detect for Freefall Protection; (10)Signal Conditioning with Low Pass Filter; (11)Robust Design, High Shocks Survivability; (12)RoHS Compliant; (13)Environmentally Preferred Product; (14)Low Cost.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
MMA7361LCT
MMA7361LCT

Freescale Semiconductor

Board Mount Accelerometers 1.5G XYZ LOW G ANALOG

Data Sheet

0-1: $1.23
1-25: $1.14
25-50: $1.10
50-100: $1.07
Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
MMA701A
MMA701A

Other


Data Sheet

Negotiable
MMA707
MMA707

Other


Data Sheet

Negotiable
MMA709
MMA709

Other


Data Sheet

Negotiable
MMA710
MMA710

Other


Data Sheet

Negotiable
MMA7260Q
MMA7260Q

Freescale Semiconductor

Board Mount Accelerometers 1.5G Sensor Accel 3 Axis

Data Sheet

Negotiable
MMA7260QR2
MMA7260QR2

Freescale Semiconductor

Board Mount Accelerometers 1.5G XYZ LEADS

Data Sheet

Negotiable
