SST49LF004A-33-4C-NH

flash memory, PLCC, -0.5V to VDD+0.5V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~2.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.00~2.00

PartNumber:: SST49LF004A-33-4C-NH

Brand:: Silicon Storage Technology, Inc - SST | Pack: PLCC | D/C: 06+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Kendy Chen's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-07-19

From Other Seller

Part Number:SST49LF004A-33-4C-NH
US $1.00 - 2.00
EKY-160ELL121MF11D

US $0.10 - 1.00 / Piece
(0) Remove
iphone5 data cable

US $4.00 - 5.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The SST49LF004A-33-4C-NH flash memory device is designed to be read-compatible with the Intel 82802 Firmware Hub (FWH) device for PC-BIOS application. The SST49LF004A-33-4C-NH provides protection for the storage and update of code and data in addition to adding system design flexibility through five general purpose inputs. Two interface modes are supported by the SST49LF004A-33-4C-NH: Firmware Hub (FWH) Interface Mode for In-System programming and Parallel Programming (PP) Mode for fast factory programming of PC-BIOS applications.

Parametrics

SST49LF004A-33-4C-NH absolute maximum ratings: (1)Temperature Under Bias: -55℃ to +125℃; (2)Storage Temperature: -65℃ to +150℃; (3)D. C. Voltage on Any Pin to Ground Potential: -0.5V to VDD+0.5V; (4)Transient Voltage (<20 ns) on Any Pin to Ground Potential: -2.0V to VDD+2.0V; (5)Package Power Dissipation Capability (Ta=25℃): 1.0W; (6)Surface Mount Lead Soldering Temperature (3 Seconds): 240℃; (7)Output Short Circuit Current: 50 mA.

Features

SST49LF004A-33-4C-NH features: (1)Firmware Hub for Intel 8xx Chipsets; (2)2 Mbit, 3 Mbit, 4 Mbit, or 8 Mbit SuperFlash memory array for code/data storage; (3)Flexible Erase Capability; (4)Single 3.0-3.6V Read and Write Operations; (5)Superior Reliability; (6)Low Power Consumption: Active Read Current: 6 mA (typical), Standby Current: 10 μA (typical); (7)Fast Sector-Erase/Byte-Program Operation; (8)Two Operational Modes: Firmware Hub Interface (FWH) Mode for in-system operation, Parallel Programming (PP) Mode for fast production programming.
